Alpine CDE-190R Single Din Radio CD MP3 USB Player Stereo Head Unit
The CDE-190R is the affordable single-DIN solution that steps up your sound to premium Alpine quality, for hours of music enjoyment.
With a direct USB and auxiliary input available conveniently on the front of the head unit you can connect to additional devices. Supporting a 1000mA USB power supply, you can connect and power portable USB hard disks. This makes it possible for you to enjoy your whole music library inside your car.
The CDE-190R head units provide a fast-charge function to a maximum of 1000mA, for quick recharging of your phone battery; perfect when you're on the go.
Features
Tuner
Memory Presets: Preset Stations (FM:18, MW:6, LW:6)
Memory: Auto Memory
Seek Mode: Local/DX Selection
RDS
RDS Functions: AF, TA, TP, PTY, EON, Radio Text
Disc Player
Disc Type: CD Player
Disc Playback Type: CD, CD-R/RW
Music Playback: CDDA, MP3, WMA, AAC Playback
M.I.X. Random Play: M.I.X. Mode
Repeat
Playback Control: Play/Pause/Forward/Backward
CD Text Display: Disc/ Track display
CD Text Name Search
Percentage Search (MP3/AAC/WMA Only)
Zero data Mute
DAC: Multi Bit DAC
Digital Servo
USB Media Connection
USB Connection: Front USB Connection with 1000mA charging support and Phone quick charging
Music Playback: MP3, WMA, AAC Playback
USB Class: Mass Storage Class
File/Folder Name Search
Percentage Search
Folder Up/Down
M.I.X. Random Play: Files in a folder, All
Repeat
Sound Tuning
Bass Engine SQ
Subwoofer Level Adjustment
Subwoofer Phase Select
Subwoofer System Select: Subwoofer Level Control Management
Low Pass Filter
Default Equaliser setup
Equaliser: Flat, Pops, Rock, News, Jazz, Electrical Dance, Hip Hop, Easy Listening, Country, Classic
3-band Parametric Equaliser
Factory EQ: 10 types
Tone control: Bass/Mid/Treble
Loudness
Source Tone Memory
Power IC Management System
General
Power Output: 4 x 50W High Power Amplifier
Display LCD: 13 Segments White LCD Display 1Line
Illumination: 2 illumination Colours Selectable (Green/Red)
Control Type: Rotary Encoder Knob
2 PreOuts (2V, Front + Rear/Subwoofer)
AUX-In: Front AUX Input (3.5mm mini jack)
Steering Wheel Remote Control Ready
Remote Control Ready
Menu Language: English, German, French, Italian, Spanish, Dutch, Russian
Detachable DIN Trim Plate
Detachable Face Plate
Dimmer
Power Antenna Lead Output
Remote Turn-On Output
Face Color: Black
Mute: -20dB Mute (Remote control only)
FM Tuner
Tuning Range: 87.5 - 108.0 MHz
Mono Usable Sensitivity: 0.7 μV
Alternate Channel Selectivity: 80 dB
Signal-to-Noise Ratio: 65 dB
Stereo Separation: 35 dB
Capture Ratio: 2 dB
Dimensions
Weight: 1.24 kg
Chassis Size (W x H x D) mm: 178 x 50 x 161,5 mm
Nose Piece Size (W x H x D) mm: 170 x 46 x 25 mm
Extra Information
- High Quality Alpine Audio
- A choice of two illumination options
- Perfect for upgrading your current Audio Set up
- A variety of playback options (CD, USB, Radio)
- Fits most Mercedes-Benz Models
